6-Pin DPDT Rocker Switch
Comprehensive Wiring Guide & Diagrams
1. Pin Identification
A standard 6-Pin Double Pole Double Throw (DPDT) switch has two separate circuits controlled by one actuator.
Middle Row (2 & 5): Power Input / Common.
Top & Bottom Rows: Outputs for Position A and Position B.
Option A: Motor Reverse Polarity
Wiring Diagram
Dashed/Opq lines represent the "X" jumper wires.
-
1
Power Input: Connect Battery (+) to Pin 2 and Battery (-) to Pin 5.
-
2
Create the X: Add a jumper wire from Pin 1 to Pin 6. Add another jumper from Pin 3 to Pin 4.
-
3
Connect Motor: Connect your motor wires to Pin 1 and Pin 4.
Option B: Dual Isolated Circuits
Use this to control two completely separate devices (e.g., a Light and a Pump) at the same time.
-
L
Left Side (1-2-3): Controls Circuit A. Connect Power A to Pin 2, Device A to Pin 1.
-
R
Right Side (4-5-6): Controls Circuit B. Connect Power B to Pin 5, Device B to Pin 4.
